Name: Battery Spot Welder Resistance Welding Machine Capacitive Energy Spot Welder Stainless Steel Spot Weld Machine Price
Brand: Guangdong Hwashi Technology inc.
SKU: WL-C-2K
Price: 157,805.00 USD
Availability: InStock

ホーム > 製品 > スポット溶接機械 >

Battery Spot Welder Resistance Welding Machine Capacitive Energy Spot Welder Stainless Steel Spot Weld Machine Price

stainless steel spot welder

capacitive energy spot welding machine

battery spot welder with warranty

起源の場所:

中国

ブランド名:

HWASHI

証明:

CE/CCC/ISO

モデル番号:

WL-C-2K

送信

引用を要求しなさい

製品詳細

モデル:

WL-C-2K

定数電源 (KVA):

該当する資料:

ステンレス鋼、炭素鋼、アルミニウム、金属

最大短回路電流 (KA):

標準:

CE/CCC/ISO

電極力 (KG):

100

支払及び船積みの言葉

最小注文数量

1セット

価格

交渉可能

パッケージの詳細

海にふさわしい木製パッケージ

受渡し時間

あなたの支払いを受け取ってから7-30営業日

支払条件

L/C、T/T

供給の能力

月額50セット

HWASHI Wire Diameter 2-8mm Automatic ring making butt welding machine Circle Ring Bar Pneumatic Resistance Butt Welding Machine

お問い合わせ

ビデオ

Hwashi Customizable AC Pulse Spot Welding Machine for Different Welding Requirements in Hardware Industry

お問い合わせ

ビデオ

HWASHI Wire Frame T Butt Welding Machine

お問い合わせ

ビデオ

Battery Spot Welder Resistance Welding Machine Capacitive Energy Spot Welder Stainless Steel Spot Weld Machine Price

お問い合わせ

送信

+8613380655800

marketing@hwashi.com

今接触

製品の説明

220v battery spot welder resistance welding machine capacitive energy spot welder Stainless Steel spot weld machine price

Battery Spot Welder Resistance Welding Machine Capacitive Energy Spot Welder Stainless Steel Spot Weld Machine Price 0

Capacitor discharge spot welding machine is a kind of electrical energy storage spot welder, which is used to charge the capacitor after rectifier rectification of AC power, and then the stored electric energy is converted into a low electric voltage, and the energy is relatively concentrated and stable pulse current, then the metal is fused through the resistance heat generated at the contact point of the welding workpiece.

Battery Spot Welder Resistance Welding Machine Capacitive Energy Spot Welder Stainless Steel Spot Weld Machine Price 1

Battery Spot Welder Resistance Welding Machine Capacitive Energy Spot Welder Stainless Steel Spot Weld Machine Price 2

Features of The Capacitor Discharge Spot Welding Machine
1.The requirements for the power grid are low and do not affect the power grid.
2.The welding process is short, the instantaneous current is high, and the heat affected zone is small.
3.The water cooling circulation system helps to effectively reduce the consumption of electrodes and transformers.
4.The welding surface oxidation and deformation is small, no black coating, and no grinding process is required after welding.

Model	WL-C-2K
Input Power (V/φ)	220/1
Rated Power (KVA)	2
Applicable Material	Stainless Steel, Carbon steel, Aluminum, Metal
Max Short Circuit Current (KA)	1
Electrode Force (KG)	100
Electrode Stroke (MM)	50
Dimension(LWH)	545mm550mm1250mm
Warranty	1 years
